BT3.0 Bluetooth OBD2 Scanner Diagnostic Tool for 12V Cars - Fault Code Reader
Product Name: bluetooth Car Auto Diagnostic Interface Scanner;
Communication method: Bluetooth;
bluetooth version: BT3.0;
bluetooth connection password: 1234;
bluetooth effective distance: within 10 meters of obstacles; within 30 meters of obstacles;
Output protocol: RS232;
Baud rate: 38400;
Product material: ABS;
Product net weight: 20g;
Product gross weight: 30g;
Product size: 4.8*2.5*3.2cm;
Packing size 11*6.5*2.5 cm;
Working voltage: DC 9-16V;
Working current: 45 mA;
Working temperature: -40 ° C to 80 ° C;
Supported Vehicle Agreements:
1) ISO9141-2 (5 baud initialization, 10.4K baud);
2) ISO14230-4 KWP (5 baud initialization, 10.4 Kbaud);
3) ISO14230-4 KWP (Quick Initialization, 10.4 Kbaud);
4) ISO15765-4 CAN (11-bit ID, 500 Kbaud);
5) ISO15765-4 CAN (29-bit ID, 500 Kbaud);
6) ISO15765-4 CAN (11-digit ID, 250 Kbaud);
7) ISO15765-4 CAN (29-bit ID, 250 Kbaud);
-SAE J1939 CAN (29-bit ID, 250 * Kbaud);
-USER1 CAN (11 * bit ID, 125 * Kbaud);
-USER2 CAN (11 * bit ID, 50 * kbaud);
Compatible Devices and Software:
for Android phone: TORQUE software;
for Symbian phone: OBDscope software;
for Windows 7 / XP system computer: ScanMaster-ELM software;
Features:
1. bluetooth 3.0, the connection is faster and more stable;
2. Plug and play, quick installation;
3. Mini size, easy to carry, does not affect driving after installation;
Function:
It is a new high quality automotive fault detector in 2020 with the following features:
1. Read the fault code and display the code definition;
2. Clear the general fault code and turn off the fault indicator (some important fault codes need to be repaired
before they can be completely cleared);
3. Read real-time speed;
4. Engine speed;
5. Coolant temperature;
6. Battery voltage;
7. Vehicle agreement type;
8. Vehicle identification code;
9. Display sensor data;
10. Calculate the load value;
11. Fuel system status;
12. Short-term fuel adjustment;
13. Long-term fuel adjustment;
14. Absolute throttle position;
15. Oxygen sensor voltage;
16. Short-term fuel adjustment;
17. Fuel system status;
18. Fuel pressure;
19. Throttle pressure;
20. Timing in advance;
21. Intake air temperature;
22. Air flow and more.
Vehicles Are Not Supported:
E01 products do not support trucks, trucks, carts, and 24V powered vehicles.
Support Vehicles:
The product supports most of the 12V-powered cars produced after 1996.
Packages Included:
1 x E01 bluetooth Car Diagnostic Interface Scanner;
1 x English operating instructions;
1 x Package Box.
